Product Description
For many projects, the precise location of drilled holes can make or break the job. You can try your luck with guesswork and jigs, but you'll rest easier with the Grizzly G4185 Horizontal Boring Machine. This precision machine delivers predictable, highly accurate results every time. Your workpiece won't slide away from the bit because the powerful pneumatic clamp exerts over 600 lbs of force! Plus, this versatile workhorse allows the use of multi-bit boring heads to make your workflow even more efficient. Shown with optional Boring Head. SPECIFICATIONS: ? Table Size: 15-3/4"W x 9-3/4"D ? Spindle Travel: 3" ? Table Travel, Vertical: 3" ? Speed: 3450 RPM ? Motor: 2 HP, TEFC, 220V, single phase ? Amps: 12 ? Power Transfer: Direct ? Air Consumption: .5 CFM ? Maximum SPM: 12 @ 90 PSI FEATURES: ? Cast iron table ? Dovetailed miter gauge and slot ? Pneumatic clamp and spindle travel ? 9/16" maximum hole capacity ? Accepts RH threaded boring bits ? Pre-formed steel stand ? Dovetailed table ways ? Size: 47-1/2" H x 15" W x 37-1/4" D ? Shipping weight approx. 346 lbs.
